Hexadecimal to Octal Conversion

Hexadecimal to Octal Conversion” is a one of the classic programming problem exercise. Here, we are given a hexadecimal number, entered by user and our task is to write a program to convert the given hexadecimal number to its equivalent octal number.

Example (Hexadecimal to Octal Conversion):

HEXADECIMAL = 32A
OCTAL = 1452

The steps required for Hexadecimal to Octal Conversion are as follows:

  1. Scan the hexadecimal number from left to right digit by digit.
  2. Convert each digit of hexadecimal number into its corresponding 4-digit binary number, combine them and store it into temporary variable ‘hexadecimal_binary’.
  3. Make sure the number of digits of ‘hexadecimal_binary’ are divisible by 3. If not, add extra remaining 0s in the front of ‘hexadecimal_binary’.
  4. Now, distribute the ‘hexadecimal_binary’ into pairs of 3-digit binary numbers.
  5. Then, convert each 3-digit pair into corresponding Octal number.
  6. Combine the character and get the result.
  7. Print the result.

C++ Program for hexadecimal to octal Conversion is as follows:

/* C++ Program for Hexadecimal to Octal Conversion */
#include<bits/stdc++.h>
using namespace std;
int bin2Dec(string binary)
{
    int decimal = 0;
    int iterator = 2;
    for(int i = 0; i < 3; i++)
    {

        char digit = binary[i];
        if(digit == '1')
        decimal = decimal + (1 * pow(2,iterator)); /* Putting it into formula */
        iterator--;
    }
    return decimal;
}
int main()
{
    /* Scan the hexadecimal Number */
    string Hexadecimal;
    cout<<"Enter the Hexadecimal Number: ";
    cin>>Hexadecimal;

    /* Converting Hexadecimal to octal*/
    string hexadecimal_binary;
    /* Converting each digit of hexadecimal number
       to 4-digit binary number and store the
       combined result into 'hexadecimal_binary'
    */
    for(int i = 0; i < Hexadecimal.length(); i++)
    {
        string temp;
        switch(Hexadecimal[i])
        {
            case '0': temp = "0000";
            break;
            case '1': temp = "0001";
            break;
            case '2': temp = "0010";
            break;
            case '3': temp = "0011";
            break;
            case '4': temp = "0100";
            break;
            case '5': temp = "0101";
            break;
            case '6': temp = "0110";
            break;
            case '7': temp = "0111";
            break;
            case '8': temp = "1000";
            break;
            case '9': temp = "1001";
            break;
            case 'A': temp = "1010";
            break;
            case 'B': temp = "1011";
            break;
            case 'C': temp = "1100";
            break;
            case 'D': temp = "1101";
            break;
            case 'E': temp = "1110";
            break;
            case 'F': temp = "1111";
        }
        /* Combining the 3-digit binary numbers */
        hexadecimal_binary = hexadecimal_binary + temp;
    }

    /* Length of 'hexadecimal_binary' must be multiple of 3 */
    if(hexadecimal_binary.length() % 3 != 0)
    {
        /* Inserting Extra 0s in front, if needed */
        while(hexadecimal_binary.length() % 3 != 0)
        {
            hexadecimal_binary.insert(0,"0");
        }
    }

    /* Distribute 'hexadecimal_binary' into pairs of 3-digit,
       convert them into decimal equivalent which will be octal
       equivalent
    */
    string Octal;
    for(int i = 0; i < hexadecimal_binary.length(); i=i+3)
    {
        string temp = "";
        temp+= hexadecimal_binary[i];
        temp+= hexadecimal_binary[i+1];
        temp+= hexadecimal_binary[i+2];

        /* Converting 'temp' into decimal */
        int decimal = bin2Dec(temp);

        /* Converting decimal to corresponding Hexadecimal */
        switch(decimal) {
            case 0 :
                Octal = Octal + '0';
                break;
            case 1 :
                Octal = Octal + '1';
                break;
            case 2 :
                Octal = Octal + '2';
                break;
            case 3 :
                Octal = Octal + '3';
                break;
            case 4 :
                Octal = Octal + '4';
                break;
            case 5 :
                Octal = Octal + '5';
                break;
            case 6 :
                Octal = Octal + '6';
                break;
            case 7 :
                Octal = Octal + '7';
                break;
        }
    }

    /* Truncating Extra 0s from beginning, if any */
    while(Octal[0]=='0')
    {
        Octal.erase(Octal.begin()+0);
    }

    /*Printing the result */
    cout<<"The Octal of "<<Hexadecimal<<" is "<<Octal;
}

OUTPUT:
Enter the Hexadecimal number: 32A
The Octal of 32A is 1452
